Control MS-L

plus

Description de la série de fabrication

Functions

"Drain" operating mode: For draining waste water shafts in water disposal
Configurable overload protection
Thermal motor monitoring
Pump kick function for 2 sec
Adjustable follow-up time up to 120 sec
Pump cycling after each run (for switchgear for 2 pumps)
Rotation direction monitoring
High water alarm with forced switch-on of the connected pump(s)
Fault memory of the last fault
Enhanced functionality when used with lifting units; e.g. display service interval

Equipment

Lockable main switch (depending on version)
Control panel with buttons
Display of the current operating or fault conditions via LED
Configurable electronic motor current monitoring
Configuration of individual functions using dip switches and potentiometers
Integrated alarm buzzer, mains-independent via 9 V battery (optionally available as accessory)
