Wilo-Atmos GIGA-N

The standard pump for universal applications and a long service life.
The Wilo-Atmos GIGA-N is the entry-level model for glanded pumps. The wide range of motors and materials to choose from plus its wide temperature range from -20 to +140 °C make it a real all-rounder for a whole host of different applications.
Designed specifically for continuous operation, the pump also boasts a long service life thanks to its corrosion-resistant coatings and maintenance-free roller bearings. If maintenance is required, the spacer coupling ensures the mechanical seal can be replaced as quickly as possible. The speed of the Wilo-Atmos GIGA-N is controlled by a Wilo-EFC converter. It can be fitted with temperature and vibration monitoring for the pump bearing so that impending breakdowns can be recognised in good time.
With that in mind, Wilo also offers additional, complementary services ranging from commissioning through to maintenance, and the comprehensive full-service WiloCare package is designed to ensure optimal operational reliability via Wilo remote monitoring.
Your advantages
- Energy-saving thanks to increased overall efficiency through improved hydraulics and the use of IE3 motors
- Suitable for drinking water supply (ACS-, UBA- compliant)
- Cataphoretic coating of all cast components for high corrosion resistance and long service life (not available for the drinking water version)
- Universally usable thanks to standardised dimensions, a range of motor options and impellers made of different materials
- Easy maintenance thanks to user-friendly spacer coupling in back pull-out design
- High operational reliability thanks to improved impeller construction for pressure reduction

The Wilo-Atmos GIGA-N is also ready for use with drinking water applications.


The convenient service package for existing Wilo pumps and systems
With Wilo-Care Connect you stay up-to-date about the current status of your system, including energy consumption and possible optimisations or malfunctions.
more informationThe upgrade module for digital pump access
The Wilo-Smart IF module offers the option of making earlier-generation Wilo pumps accessible for Wilo-Smart connect, allowing the user to control them via remote access on the Wilo-Gateway or locally via Bluetooth interface.
more informationStand-alone frequency converter
This frequency converter for wall fixation can be installed in fixed speed pumps with asynchronous or permanent magnet motors for various applications, in particular for heating, air conditioning and pressure boosting.
more informationThe entire world of pumps in one app
The “Wilo Assistant” makes the entire world of high-efficiency pump technology available on smartphones and tablets for sanitation, heating and air-conditioning specialists and specialist consultants of technical building equipment.
read moreCarefree package for your everyday working life
With Wilo as your partner, you cannot only be sure of choosing high-quality product solutions, but also of benefiting from a comprehensive, carefree package of well-thought-out services.
read moreSeries description



Your advantages
- Energy-saving thanks to increased overall efficiency through improved hydraulics and the use of IE3 motors
- Suitable for drinking water supply (ACS-, UBA- compliant)
- Cataphoretic coating of all cast components for high corrosion resistance and long service life (not available for the drinking water version)
- Universally usable thanks to standardised dimensions, a range of motor options and impellers made of different materials
- Easy maintenance thanks to user-friendly spacer coupling in back pull-out design
- High operational reliability thanks to improved impeller construction for pressure reduction
The standard pump for universal applications and a long service life.
The Wilo-Atmos GIGA-N is the entry-level model for glanded pumps. The wide range of motors and materials to choose from plus its wide temperature range from -20 to +140 °C make it a real all-rounder for a whole host of different applications.
Designed specifically for continuous operation, the pump also boasts a long service life thanks to its corrosion-resistant coatings and maintenance-free roller bearings. If maintenance is required, the spacer coupling ensures the mechanical seal can be replaced as quickly as possible. The speed of the Wilo-Atmos GIGA-N is controlled by a Wilo-EFC converter. It can be fitted with temperature and vibration monitoring for the pump bearing so that impending breakdowns can be recognised in good time.
With that in mind, Wilo also offers additional, complementary services ranging from commissioning through to maintenance, and the comprehensive full-service WiloCare package is designed to ensure optimal operational reliability via Wilo remote monitoring.
Construction
Single-stage, low-pressure centrifugal pump with axial suction, mounted on a baseplate. Standard version with spacer coupling.
Application
- The pumping of heating water (in accordance with VDI 2035), cold water and water-glycol mixtures without abrasive substances in heating, cold water and cooling systems.
- Applications for irrigation, building services, general industry, power stations, etc.
Equipment/function
Single-stage low-pressure centrifugal pump in monobloc design with coupling, coupling guard, motor and baseplate
- Mechanical seal
Scope of delivery
- Pump
- Installation and operating instructions
- Bare shaft pump or
- Pump on baseplate with coupling and coupling guard, without motor or
- Completely mounted pump on baseplate with electric motor
Type key
Example | Atmos GIGA-N 40/200-11/2 |
Atmos | Product family |
GIGA | Series designation |
N | Standard pump with axial suction |
40 | DN for the pressure flange |
200 | Impeller nominal diameter [mm] |
11 | Rated power P2 [kW] |
2 | Number of poles |
Technical data
- Permissible temperature range of -20 °C to +140 °C
- Mains connection 3~400 V, 50 Hz
- Protection class IP55
- Nominal diameter DN 32 to DN 150
- Max. operating pressure 16 bar
Materials
- Pump housing and lantern. Standard: EN-GJL-250
- Impeller: Standard: EN-GJL-200; others on request
- Shaft: 1.4021
- Mechanical seal: AQEGG; other mechanical seals on request
Description/construction
- Single-stage low-pressure centrifugal pump as baseplate pump with axial suction ports with flanged bearing brackets and axle fastening for flexibly coupled drives
- Spacer coupling (sleeve coupling) is standard; this provides the option of leaving the motor in position when dismantling the rotor unit
- Variant ...-P5 without spacer coupling (at reduced price, see price list)
Duty chart
Wilo-Atmos GIGA-N (2pl)

Wilo-Atmos GIGA-N (4pl)
