Single-stage glanded centrifugal pump in monobloc design for installation on a base. Low-vibration and low-noise monobloc design with lantern and rigidly connected standard motor. With force-flushed, bidirectional bellows mechanical seal (from 37 kW/4-pole and 45 kW/2-pole, optionally available with a cartridge mechanical seal in back pull-out design for mechanical seal replacement without dismantling the motor) and cavitation-reducing impeller. Flange with R 1/8 pressure measuring connections. Pump housing and lantern are cataphoretic-coated. Motors in IE3 technology as standard. Pump with motor ≥ 5.5 kW are equipped as standard with a PTC thermistor sensor for motor protection.

Operating data

• Fluid media
  Water
• Maximum operating pressure PN
  16 bar
• Minimum efficiency index (MEI)
  0.4

Motor data

• Motor efficiency class
  IE3
• Mains connection
  3~400 V, 50 Hz
• Voltage tolerance
  ±10 %
• Rated power P₂
  7500.0 W
• Rated speed n
  1450 rpm
• Rated current I_N
  14.90 A
• Power factor cos φ
  0.81
• Motor efficiency η_M 50%
  87.4
• Motor efficiency η_M 75%
  89.3
• Motor efficiency η_M 100%
  89.8
• Insulation class
  F
• Protection class
  IP55

Materials

• Pump housing
  5.1301, KTL-coated
• Impeller
  EN-GJL-200
• Shaft
  1.4122
• Shaft seal
  AQ1EGG
• Lantern
  EN-GJL-250

Installation dimensions

• Pipe connection on the suction side RPS
  DN 125
• Pipe connection on the pressure side RPD
  DN 100

Information for order placements

• Brand
  Wilo
• Product description
  CronoBloc-BL 100/220-7,5/4
• Net weight, approx. m
  159 kg
• Article number
  2121112
