Ready-for-connection, fully submersible and automatic sewage lifting unit as a double-pump system with automatic duty cycling, standby and peak-load operation. Two separate, dry-installed submersible sewage pumps in three-phase version with sheath flow cooling, stainless steel housing and thermal motor monitoring. One gas-tight and water-tight collection reservoirs made from plastic with clearly defined inlet connections and level control with level sensor. Microprocessor-controlled switchgear with

• LEDs for displaying operating status and error messages
• Adjustable follow-up time
• Integrated and mains-dependent alarm
• 1x potential-free contact for connection of a collective fault signal (SSM).

Scope of delivery:

• Sewage lifting unit ready for connection with switchgear
• 1x collar for diaphragm hand pump connection
• 1x inlet connection DN 150
• 1x collar for venting connection DN 70
• 1 x kit for connection of tank and pump

Attention: To install required fittings (e.g. Y-pipe, gate valve and non-return valve), they must be ordered as an accessory!

Materials

• Motor housing
  1.4404, X2CrNiMo17-12-2
• Tank material
  2509015, WILO-DrainLift XXL 1040-2/5,2
• Pump housing
  PUR Polyurethane
• Impeller
  PUR Polyurethane

Operating data

• Fluid media
  Water
• Min. fluid temperature T
  3 °C
• Max. fluid temperature T
  40 °C
• Maximum operating pressure p
  10 bar
• Max. ambient temperature T
  40 °C

Motor data

• Mains connection
  3~400 V, 50 Hz
• Shaft power P2(Q=max.) of selected impeller * number of pumps
  5200 W
• Rated current I_N
  12.80 A
• Protection class motor
  IP68
• Insulation class
  F

Installation dimensions

• Inlet connection
  DN100 / DN150
• Pipe connection on the suction side
  -
• Pipe connection on the pressure side
  DN 100

Information for order placements

• Net weight, approx. m
  195 kg
• Brand
  Wilo
• Product description
  DrainLift XXL 1040-2/5,2
• Article number
  2509015
