RexaBloc RE 15.84D-210DAH160M4

Data sheet

Product data
  • Maximum operating pressure PN
    2 bar
  • Max. fluid temperature T
    70 °C
  • Min. fluid temperature T
    3 °C
  • Max. ambient temperature T
    40 °C
  • Free ball passage of the hydraulics
    65 mm
Motor data
  • Motor design
    TEFC
  • Motor efficiency class
    IE3
  • Mains connection
    3~400 V, 50 Hz
  • Voltage tolerance
    ±10 % %
  • Rated power P2
    11.00 kW
  • Power consumption P1 max
    12.10 kW
  • Rated current IN
    20.90 A
  • Activation type
    Direct online (DOL)
  • Protection class
    IP55
  • Motor protection
    no
  • Insulation class
    F
Materials
  • Pump housing
    5.1301, EN-GJL-250
  • Impeller
    5.1301, EN-GJL-250
  • Shaft
    1.4021, X20Cr13
  • Gasket material
    NBR
  • Motor housing
    5.1301, EN-GJL-250
Installation dimensions
  • Pipe connection on the suction side
    DN 150
  • Pipe connection on the pressure side
    DN 150
Information for order placements
  • Brand
    Wilo
  • Product description
    RexaBloc RE 15.84D-210DAH160M4
  • Net weight, approx. m
    253 kg
  • Article number
    6085274

Dimensions and dimensions drawings

Wilo-RexaBloc RE 15.84D.../160M

Wilo-RexaBloc RE 15.84D.../160M
Wilo-RexaBloc RE 15.84D.../160M

Pump curves

Wilo-RexaBloc RE 15.84D — 50 Hz — No. of poles: 4

Wilo-RexaBloc RE 15.84D — 50 Hz — No. of poles: 4

Pump curves in accordance with ISO 9906, class 2B. The specified degrees of efficiency correspond to the hydraulic efficiency.

Wilo-RexaBloc RE 15.84D — 50 Hz — No. of poles: 4

Ordering information

Information for order placements
  • Brand
    Wilo
  • Product description
    RexaBloc RE 15.84D-210DAH160M4
  • EAN number
    4048482875071
  • Article number
    6085274
  • Gross weight, approx. m
    283.0 kg
  • Net weight, approx. m
    253 kg
  • Overall length L
    630.0 mm
  • Height without packaging H
    1104 mm
  • Colour
    Green
  • Packaging property
    Transport packaging
  • Packaging type
    Box
  • Number per layer
    1
  • Width without packaging L
    550.0 mm
  • Minimum order quantity
    1
  • Pieces per pallet
    1

Tender text

Single-stage, centrifugal hydraulics with IEC standard motor in compact block design for horizontal dry well installation for pumping wastewater and sewage containing faeces (in the scope of validity of EN 12050-1). Hydraulic system with axial suction ports, radial discharge ports and bearing brackets as a single unit. Bearing bracket with sealing and leakage chamber for admission of fluid ingress via the fluid and motor-side seal. Hydraulics housing, impeller and bearing bracket made of grey cast iron, sealing on the fluid side via a bidirectional mechanical seal and on the motor side via a rotary shaft seal. Optionally, the sealing chamber can be monitored with an external pencil electrode. IEC standard motor in B5 version as three-phase current motor with motor efficiency class IE3.

Operating data
  • Fluid media
    Water
  • Max. delivery head H
    14.10 m
Product data
  • Free ball passage of the hydraulics
    65 mm
  • Maximum operating pressure PN
    2 bar
  • Min. fluid temperature T
    3 °C
  • Max. fluid temperature T
    70 °C
  • Max. ambient temperature T
    40 °C
Motor data
  • Motor design
    TEFC
  • Motor efficiency class
    IE3
  • Mains connection
    3~400 V, 50 Hz
  • Voltage tolerance
    ±10 % %
  • Power factor cos φ
    0.83
  • Rated power P2
    11.00 kW
  • Power consumption P1 max
    12.10 kW
  • Rated current IN
    20.90 A
  • Starting current I
    157 A
  • Activation type
    Direct online (DOL)
  • No. of poles
    4
  • Max. switching frequency t
    10 1/h
  • Insulation class
    F
  • Protection class
    IP55
Equipment/function
  • Motor protection
    PTC
  • Sealing chamber, leakage detection
    no
  • Leakage chamber, leakage detection
    no
Materials
  • Pump housing
    5.1301, EN-GJL-250
  • Impeller
    5.1301, EN-GJL-250
  • Shaft
    1.4021, X20Cr13
  • Gasket material
    NBR
  • Motor housing
    5.1301, EN-GJL-250
Installation dimensions
  • Pipe connection on the suction side
    DN 150
  • Pipe connection on the pressure side
    DN 150
Information for order placements
  • Brand
    Wilo
  • Product description
    RexaBloc RE 15.84D-210DAH160M4
  • Net weight, approx. m
    253 kg
  • Article number
    6085274
