Cast Iron & Stainless Steel MotorPump™

Stainless Steel & Cast Iron Motorpumps™ are single stage end suction centrifugal pumps close coupled to NEMA standard motors. Features include welded 304 stainless steel, 304 and 316 stainless steel as well as Cast Iron construction with precision machined and balanced impellers secured to the motor shaft with a stainless steel locknut. Perfect alignment, exceptional seal life and quiet operation are Motorpump™ advantages. Product details and specifications can be found in our IAgricultural catalog.

Features & Benefits

  • Premium Efficient Motors
  • 0.5 - 100 HP options
  • 1750 - 3500 RPM options, 60 Hertz
  • 60 foot head - 375 foot head options

Contact a Distributor
23675DP Pump Rendering236 3500 Classic

Features & Benefits

  • .5 to 25 HP
  • 3500 RPM, 60 Hertz
  • Capacity to 385 GPM
  • 285 Foot Head
  • 8.2" Max. Impeller
  • 175 PSI Max. Working Pressure

Contact a Distributor

Group Features

  • Pump Models SSP 330, 331, 232 & 236 are NPT and have a rigid cast iron motor adapter with stainless steel cover.
  • Pump Models SSP 320, 321, 322, 323, 324, 325, 326, 327 & 328 are flanged to connect with 150 lb. ANSI flanges and have a cast iron adapter with a stainless steel cover.

Log-In to View Technical Data

Features & Benefits

  • .50 to 15 HP
  • 3500 RPM, 60 Hertz
  • Capacity to 350 GPM
  • 200 Foot Head
  • 150 PSI Max. Working Pressure

Pump Model Numbers:

  • SSE 340, 341, 342, 346
  • SSE 471S
  • SSE 501S, 503S
  • SSE 701S, 702S, 704S
Contact a Distributor

Group Features

  • J56 Frames
  • Heavy duty cast 304 stainless steel components:

Impeller Construction:

  • All Models have PPS GF composite Impeller except SSE 471.
  • Pump SSE 471S has a Cast Stainless Steel Impeller

Motor Enclosures:

  • TEFC and Explosion Proof Options

Log-In to View Technical Data

Features & Benefits

  • .50 to 15 HP
  • 3500 RPM, 60 Hertz
  • Capacity to 450 GPM
  • 125 Foot Head
  • 5.63" Max. Impeller
  • 150 Max Working pressure on J56 frame models 175 Max Working pressure on TC frame models

Pump Model Numbers

  • SSE 223S
  • SSE 602S, 604S, 605S

Contact a Distributor

Group Features

  • Best in Class Efficiency on all models except SSE 223S
  • 316 Stainless Steel

Stub Shaft design:

  • Impellers are keyed to a 316SS stub shaft and secured by a 316SS retaining assembly


Log-In to View Technical Data

Looking for More Information on the SS and Cast Iron Motorpump™ Series

  • Log in to the Scot Pump Catalog Center to view our Pump Curves, AutoCAD curves, 3D Models, exploded views, repair part numbers, IOM manuals and complete PDF data packets.

Visit Catalog Center
