Wilo-Medana PE3

Safe and quiet pressure boosting in a residential environment.

Your advantages
Wilo-Medana PE3

Safe and quiet pressure boosting in a residential environment.

The Wilo-Medana PE3 is a ready-to-plug, pressure boosting centrifugal pump, which is also suitable for use in residential environments thanks to its compact design and quiet operation. The pump is equipped with numerous protective functions and is easy to adjust via an operating button. LED control lights indicate the set operating mode at all times.


Your advantages

  • Easy installation thanks to ready-to-plug and compact design
  • Extremely low-noise (45 dbA) and thanks to its drinking water certification it can be used in a residential environment
  • Safe operation due to numerous integrated protective functions
  • Lower energy consumption thanks to automatic regulation
  • User-friendly operating panel with control lamps
Series description

Construction

Non self-priming multistage centrifugal pump

Application

  • Automatic low-noise water supply/pressure boosting for residential properties

Equipment/function

  • Low-noise operation due to fluid-cooled motor
  • Drinking water approval for all parts that come into contact with the fluid
  • Electrical connection cable incl. mains plug
  • Two constant speeds (Mode 1, Mode 2) in automatic or manual operation
  • Control lamps (LED) for the operating status
  • Pressure compensation vessel for constant operating pressure
  • Thermal motor protection
  • Integrated pressure sensor for:
    • automatic operation,
    • dry-running protection and overpressure protection
  • Integrated temperature sensor for:
    • motor blocking protection,
    • excess temperature protection and anti-freezing protection

Scope of delivery

  • Pump
  • Installation and operating instructions

Type key

Example:

Wilo-Medana PE3-350EA

Medana

Multistage Pump

PE3

PE = Pump ECO, 3 = Standard series

35

Performance indicator: 35 x 10 = 350 W

0

Serial number

E

Frequency 50 Hz

A

Automatic

Technical data

  • Mains connection 1~230 V ± 10 %, 50 Hz
  • Connection (pressure side and suction side): Rp1
  • Fluid temperature: 0 °C to +35 °C
  • Ambient temperature: -10 °C to 50 °C
  • Storage temperature -20 °C to +70 °C
  • Max. inlet pressure: 1.5 bar (in operating mode 2)
  • Max. operating pressure: 3.3 bar (in operating mode 2)
  • Start-up pressure: 1.0 bar (operating mode 1) / 1.5 bar (operating mode 2 and 3)
  • Switch-off pressure: 1.8 bar
  • Protection class: IPX4

Materials

  • Pump housing: Plastic
  • Impeller: Plastic
  • Shaft: Stainless steel
  • Mechanical seal: Carbon/ceramic
