Wilo-管状水泵

Wilo-VT

Space saving
Engineeres product: pumps are available in variety of materials and construction configurations that can meet exacting requirements of customers
Pump hydraulics delivers high pumps efficiencies

Vertical Turbine 50 Hz

Standardized vertical turbine pumps for dry well installation with submerged axial or semi-axial hydraulics.

The vertical turbine pump designs is normally used in

high-flow applications:

Example:	Atmos TERA-VMF11A03-100/4-V2-A-L2-CACBDA-IE3
Atmos	Product family
TERA	Series
VMF	Pump type (vertical mixed flow)
11A	Nominal flow Q (at BEP/100)
03	Number of stages
100	Rated motor power P₂ in kW
4	Number of poles
V2	Index for voltage and frequency V2 = 3~400/690 V ±10 % 50 Hz

lmpeller: Cast lron, Bronze Stainless Steel, Ni-Cl, Cast Steel, Duplex, Super Duplex
Diffuser: Cast lron, Stainless Steel, Ni-Cl, Cast Steel, Duplex, Super Duplex
Shaft: Stainless Steel [EN8, EN19, SS 304, SS 410, SS410H, SS 316L, UNS]
Shaft sleeve: Carbon Steel [EN8],Stainless Steel [SS 304,SS 410, SS410H, SS 316L, UNS ]
Casing wear ring: Cast lron, Bronze Stainless Steel, Ni-Cl
lntermediate bearing: FINOCOT, THORDON, FEROFORM, Cut-less Rubber
Bell mouth: Cast lron, Stainless Steel, Ni-Cl, Cast Steel, Duplex, Super Duplex
RM Pipes¹: Mild Steel, Stainless Steel
DBMS²: Mild Steel, Stainless Steel

¹ RM Pipes: Rising Main Pipe

² DBMS : Delivery Bend cum Motor Stool

Other material combinations available on request
